LIFT & SLIDE 120 TH

Sliders

Description

AX-120 is a thermally insulated sliding system designed for optimum quality, high insulation, and ease of operation. With a low threshold, it ensures seamless continuity between indoor and outdoor spaces, enhancing accessibility. Ideal for premium projects, the system supports large glass panels while delivering superior thermal performance and security.

Key Features

  • Insulated lift & slide system
  • Basic profile depth of outer profile: 120 mm
  • Multi-point locking solution
  • Surface-mounted fittings

    • ‍

    ‍

    Dimensions

  • Maximum vent size (W x H): 2000 mm x 3600 mm
  • Maximum vent weight: 200 kg

    • ‍

    Technical Specifications

  • Glazing thickness: 24 mm to 32 mm
  • Multi-point locking system
  • Profile powder coating
  • Fittings: Black

    • ‍

    Technical Diagram
