LIFT & SLIDE 150 TH

Sliders

Description

The AX-150 Lift & Slide system offers exceptional performance, enhanced burglar resistance, and versatile design options. Combining improved monorail, 2-rail, and 3-rail configurations into a single system, it supports thicker glass panels up to 400 kg. With optimized thresholds, enriched insulation, and the option for inside glass blinds, the AX-150 delivers both functionality and elegance, with provisions for natural air ventilation.

Key Features

  • Insulated lift & slide system
  • Basic profile depth of outer profile: 150 mm
  • Multiple opening configurations
  • Surface-mounted fittings

    • ‍

    Dimensions

  • Maximum vent size (W x H): 3000 mm x 3600 mm
  • Maximum vent weight: 400 kg

    • ‍

    ‍

    Technical Specifications

  • Glazing thickness: 28 mm to 48 mm
  • Profile powder coating
  • Multi-point locking system
  • Fittings: Black

    • ‍

    Technical Diagram
